30t/h Rice Husk Fired Circulating Fluidized Bed Boiler For Power Pant
Product description
1. The fuel adaptability is strong, can meet a variety of fuel combustion.
2. High degree of automation, can keep the boiler safe and economic operation in long time.
3. The boiler combustion efficiency is as high as 95% ~ 99%, fuel efficiency is high, the boiler thermal efficiency can reach above 87%, energy saving, high efficiency.
4. Using the exhaust temperature cyclone separating device, bed material high collection rate, furnace heat transfer coefficient is high, the overload ability.
5. The boiler load adjustment range is big, can be adjusted within the scope of 110% ~ 30%, particularly suitable for large range of boiler load fluctuations.
6. The bed material can be added in the limestone, combustion reaction with SO2 in flue gas generated in the process of sulfate, the desulfurization effect meet the requirements of environmental protection, at the same time chamber of a stove or furnace combustion temperature is low, can inhibit the formation of NOX, truly green burning.
Circular flow bed CFB boiler technical parameters
| Model | Rated evaporation | Work pressure | Steam temperature | Water supply temperature | Fuel consumption | Thermal efficiency | Dimensions |
| Unit | t/h | MPa | ℃ | ℃ | Kg/h | % | mm(Long x wide x high) |
| DHX20-1.25 | 20 | 1.25 | 194 | 104 | 2475 | 91 | 12000x8160x22120 |
| DHX20-1.6 | 20 | 1.6 | 204 | 104 | 2483 | 91 | 12000x8160x22120 |
| DHX20-2.5/400 | 20 | 2.5 | 400 | 104 | 2934 | 91 | 12000x8160x22120 |
| DHX25-1.25 | 25 | 1.25 | 154 | 104 | 3003 | 91 | 13000x8610x23170 |
| DHX25-1.6 | 25 | 1.6 | 204 | 104 | 3100 | 91 | 13000x8610x23170 |
| DHX25-2.5/400 | 25 | 2.5 | 400 | 104 | 3692 | 93 | 13000x8610x23170 |
| DHX30-1.25 | 30 | 1.25 | 194 | 104 | 3712 | 93 | 12170x9200x25500 |
| DHX30-1.6 | 30 | 1.6 | 204 | 104 | 3724 | 93 | 12170x9200x25500 |
| DHX30-2.5/400 | 30 | 2.5 | 400 | 104 | 4431 | 93 | 12170x9200x25500 |
| DHX35-1.25 | 35 | 1.25 | 194 | 104 | 4331 | 91 | 13800x10320x26815 |
